EN AW-6060 40 x 55 x 55 mm
Material id:
1008162
Length
55 mm
Dimension
40 mm
Dimension out
55 mm
Dimension inch
1 ½ "
Stock
Stock material
EN AW-6060
Is suitable for anodizing, and has a high corrosion resistance and good for anodizing. The alloy is suitable for welding.
We are not liable for items out of stock. The specified weight is theoretical. Please contact us if you have any further enquiries.
Technical Specifications
Alloys
| Density | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | Other | |||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Name | g/cm3 | Min | Max | Min | Max | Max | Max | Min | Max | Max | Max | Max | Max | |
| EN AW-6060 | 2.7 | Al, Aluminium | 0.3 | 0.6 | 0.1 | 0.3 | 0.1 | 0.1 | 0.35 | 0.6 | 0.05 | 0.15 | 0.1 | 0.15 |
Aluminium Properties
| Thermal conductivity | Coefficient of thermal expansion | Melting point | Elastic modulus | Electrical conductivity | |||
|---|---|---|---|---|---|---|---|
| Alloy | Temper | W/m*K | µm/(m*K) | min °C | KN/mm2 | %IACS | |
| EN AW-6060 | O | 23.4 | 610 | 655 | 69 | ||
| EN AW-6060 | T1 | 195 | 23.4 | 610 | 655 | 69 | 49.5 |
| EN AW-6060 | T4 | 187 | 23.4 | 610 | 655 | 69 | 48 |
| EN AW-6060 | T5 | 209 | 23.4 | 610 | 655 | 69 | 54 |
| EN AW-6060 | T6 | 209 | 23.4 | 610 | 655 | 69 | 54 |
